UCC21759-Q1
SLUSEB4A – AUGUST 2020 – REVISED DECEMBER 2020
www.ti.com
2.7
2.4
2.1
1.8
1.5
1.2
0.9
0.6
90
84
78
72
66
60
54
Thermal Diode VAIN
NTC VAIN
Thermal Diode APWM
NTC APWM
48
20
40
60
80
Temperature (èC)
100
120
140
VAIN
Figure 9-9. Thermal diode and NTC VAIN and Corresponding Duty Cycle at APWM
The duty cycle output has 3% variation throughout temperature without any calibration from 0.6V to 2.5V at
VAIN, as shown in Figure 9-10 but with single-point calibration at 25°C, the duty accuracy can be improved to
1%, as shown in Figure 9-11.
1.5
Thermal Diode APWM Duty Error
NTC APWM Duty Error
1.25
1
0.75
0.5
0.25
0
-0.25
20
40
60
80
Temperature (èC)
100
120
140
APWM
Figure 9-10. APWM Duty Error Without Calibration
Copyright © 2020 Texas Instruments Incorporated
44
Submit Document Feedback
