8.7.3.10 SYSCLK Status Register
The SYSCLK status register (SYSTAT) shows the status of the system clocks (SYSCLKn). SYSTAT is
shown in Figure 8-20 and described in Table 8-30.
31
16
Reserved
R-1
15
7
13
5
12
11
10
9
8
Reserved
R-1
SYS13ON
R-1
SYS12ON
R-1
SYS11ON
R-1
SYS10ON
R-1
SYS9ON
R-1
6
0
SYS8ON
R-1
SYS7ON
R-1
Reserved
R-1
LEGEND: R = Read only; -n = value after reset
Figure 8-20. SYSCLK Status Register (SYSTAT) [Hex Address: 029A 0150]
Table 8-30. SYSCLK Status Register (SYSTAT) Field Descriptions
Bit
Field
Value Description
31:13 Reserved
1
Reserved. The reserved bit location is always read as 1. A value written to this field has no effect.
12:6
5:0
SYSnON
SYSCLKn on status.
0
1
1
SYSCLKn is gated.
SYSCLKn is on.
Reserved
Reserved. The reserved bit location is always read as 1. A value written to this field has no effect.
