5.17 Arbiter Timeout Status Register
The arbiter timeout status register contains the status of each request (request 5–0) timeout. The timeout status bit
for the respective request is set if the device did not assert FRAME after 16 clocks. See Table 5–15 for a complete
description of the register contents.
Bit
7
6
5
4
3
2
1
0
Name
Type
Default
Arbiter timeout status
R
0
R
0
R
0
R
0
R/C/U
0
R/C/U
0
R/C/U
0
R/C/U
0
Register:
Type:
Offset:
Default:
Arbiter timeout status
Read-only
63h
00h
Table 5–15. Arbiter Timeout Status Register
BIT
TYPE
FUNCTION
7–4
R
Reserved. Bits 7–4 return 0s when read.
Request 3 timeout status. Cleared by writing a 1.
3
2
1
0
R/C/U
0 = No timeout (default)
1 = Timeout has occurred
Request 2 timeout status. Cleared by writing a 1.
0 = No timeout (default)
R/C/U
R/C/U
R/C/U
1 = Timeout has occurred
Request 1 timeout status. Cleared by writing a 1.
0 = No timeout (default)
1 = Timeout has occurred
Request 0 timeout status. Cleared by writing a 1.
0 = No timeout (default)
1 = Timeout has occurred
5–15
