S/UNI®-ATLAS-3200 Telecom Standard Product Data Sheet

Preliminary

TIP

The Transfer In Progress bit is logic 1 while the Input BCIF, Output BCIF, Input SDQ,

Output SDQ, or SDQ FIFO counts are being updated. Once the update is complete, TIP

becomes logic 0 to indicate that the counts are valid; however, another transfer should not be

requested for at least 100ns after TIP returns to 0.

MKT_NUM[15:0]

The Marketing Number register returns 0x7325, the marketing number of the S/UNI-S/UNI-

ATLAS-3200.
