Egress_IngressB
When Egress_IngressB is logic 1, the device is in Egress mode, and the TxPHY and TxLink
blocks are used. When Egress_IngressB is logic 0, the device is in Ingress mode and the
RxLink and RxPHY blocks are used. When in egress mode, the RxLink and RxPhy blocks
should be left in soft reset. When in ingress mode, the TxLink and TxPhy blocks should be
left in soft reset.
FREE[7:0]
These bits have no function. They can be used by software to store configuration
information, software version codes, or other user information.
Reserved
This bit must be programmed to logic 0 for correct operation..
Reserved
This bit must be programmed to logic 0 for correct operation.
