Preliminary Information
MT9076
Bit
Name
Functional Description
7 - 0
LCV7 - 0 Least Significant Bits of the LCV Counter. The least significant eight bits of a 16 bit
counter that is incremented once for every line code violation received. A line code is
defined as a bipolar violation that is not a part of HDB3 encoding where the control bit EXZ
is set low. Where EXZ is set high a violation is defined as either a non-HDB3 bipolar
violation or an occurrance of excess zeros.
Table 141 - Least Significant Bits of the LCV Counter
(Page 4, Address 17H) (E1)
Bit
Name
Functional Description
7-0
CC15 - 8 CRC-4 Error Counter These are the most significant eight bits of the CRC-6 error counter.
Table 142 - CRC-4 Error Counter CEt
(Page 4, Address 18H) (E1)
Bit
Name
Functional Description
7 - 0
CC7 - 0 CRC-6 Error Counter. These are the least significant eight bits of the CRC-4 error counter.
Table 143 - CRC-6Error Counter CEt
(Page 4, Address 19H) (E1)
119
