1-Gbit P30 Family
Figure 20.
Continuous Burst Read, showing an Output Delay Timing
R301
R302
R306
R304
R304
R304
CLK [C]
Address [A]
ADV# [V]
R2
R101
R105
R106
R303
R102
R3
CE# [E]
OE# [G]
R15
R307
R304
R312
WAIT [T]
R4
R7
R305
R305
R305
R305
Data [D/Q]
Notes:
1.
WAIT is driven per OE# assertion during synchronous array or non-array read, and can be configured to
assert either during or one data cycle before valid data.
2.
At the end of Word Line; the delay incurred when a burst access crosses a 16-word boundary and the
starting address is not 4-word boundary aligned.
April 2005
40
Intel StrataFlash® Embedded Memory (P30)
Order Number: 306666, Revision: 001
Datasheet
