PCI Express* Registers (D1:F0)
6.1.16
MLIMIT1—Memory Limit Address
B/D/F/Type:
Address Offset:
Default Value:
Access:
0/1/0/PCI
22–23h
0000h
RW, RO
16 bits
Size:
This register controls the processor to PCI Express-G non-prefetchable memory access
routing based on the following formula:
MEMORY_BASE ≤ address ≤ MEMORY_LIMIT
The upper 12 bits of the register are read/write and correspond to the upper 12
address bits A[31:20] of the 32 bit address. The bottom 4 bits of this register are
read-only and return zeroes when read. This register must be initialized by the
configuration software. For the purpose of address decode, address bits A[19:0] are
assumed to be FFFFFh. Thus, the top of the defined memory address range will be at
the top of a 1MB aligned memory block. NOTE: Memory range covered by MBASE and
MLIMIT registers are used to map non-prefetchable PCI Express address ranges
(typically where control/status memory-mapped I/O data structures of the graphics
controller will reside) and PMBASE and PMLIMIT are used to map prefetchable address
ranges (typically graphics local memory). This segregation allows application of USWC
space attribute to be performed in a true plug-and-play manner to the prefetchable
address range for improved processor - PCI Express memory access performance.
Note also that configuration software is responsible for programming all address range
registers (prefetchable, non-prefetchable) with the values that provide exclusive
address ranges i.e. prevent overlap with each other and/or with the ranges covered
with the main memory. There is no provision in the GMCH hardware to enforce
prevention of overlap and operations of the system in the case of overlap are not
ensured.
Bit
Access &
Default
Description
15:4
RW
000h
Memory Address Limit (MLIMIT): This field corresponds to
A[31:20] of the upper limit of the address range passed to PCI
Express.
3:0
RO
0h
Reserved
