PCI Express* Registers (D1:F0)
6.1.15
MBASE1—Memory Base Address
B/D/F/Type:
Address Offset:
Default Value:
Access:
0/1/0/PCI
20–21h
FFF0h
RW, RO
16 bits
Size:
This register controls the processor-to-PCI Express non-prefetchable memory access
routing based on the following formula:
MEMORY_BASE ≤ address ≤ MEMORY_LIMIT
The upper 12 bits of the register are read/write and correspond to the upper 12
address bits A[31:20] of the 32 bit address. The bottom 4 bits of this register are
read-only and return zeroes when read. This register must be initialized by the
configuration software. For the purpose of address decode, address bits A[19:0] are
assumed to be 0. Thus, the bottom of the defined memory address range will be
aligned to a 1 MB boundary.
Bit
Access &
Default
Description
15:4
RW
FFFh
Memory Address Base (MBASE): This field corresponds to A[31:20]
of the lower limit of the memory range that will be passed to PCI
Express.
3:0
RO
0h
Reserved
174
