EZ-PD™ CCG7D Automotive USB Type-C and Buck-boost Controller
Dual-port
Power subsystem
2
Power subsystem
Figure 8 shows an overview of the power subsystem architecture for CCG7D devices. The power subsystem of
CCG7D devices operate from VIN supply which can vary from 4 V to 24 V. The VDDD pin, the output of 5 V LDO gets
input from VIN supply. The VDDD pin can also be used as a power supply for external loads up to 150 mA. CCG7D
devices have two different power modes: Active and Deep Sleep, transitions between which are managed by the
power system. The VCCD pin, the output of the core (1.8 V) regulator, is brought out for connecting a 0.1-µF
capacitor for the regulator stability only. This pin is not supported as a power supply for external load.
VBUS_IN_0 VBUS_C_0 VBUS_IN_1 VBUS_C_1
NGDO
NGDO
PVDD
PVDD
Buck-Boost LS
Driver_P0
Buck-Boost LS
Driver_P1
1µF
1µF
PGND
VIN
PGND
VDDD
LDO
10µF
CC1_1
CC2_1
CC2_0
CC1_0
Core Regulator
VCCD
GND
0.1µF
2 x CC
Tx/Rx
GPIOs
Core
Figure 8
Power system requirement block diagram
Datasheet
15
002-28172 Rev. *N
2023-01-31
