IBM3009K2672
IBM SONET/SDH Framer
Miscellaneous Pin Descriptions
Pin Name
Pin No.
I/O
Type
Pin Description
Alarm Pins for Receive Macro 1:
The ALARM1(0:4) outputs are controlled real time by the same internal
control signals that also cause the corresponding microprocessor interrupt.
The alarm conditions that are output on these pins are as follows:
ALARM1(0) = Loss of Signal in Macro 1
ALARM1(1) = Loss of Frame in Macro 1
ALARM1(2) = Loss of Pointer in Macro 1
ALARM1(3) = Path AIS in Macro 1
ALARM1(4) = Line AIS in Macro 1
ALARM1(0)
ALARM1(1)
ALARM1(2)
ALARM1(3)
ALARM1(4)
H01
H03
K01
K03
K05
O
O
O
O
O
LVTTL-5sd
Alarm Pins for Receive Macro 2:
The ALARM2(0:4) outputs are controlled real time by the same internal
control signals that also cause the corresponding microprocessor interrupt.
The alarm conditions that are output on these pins are as follows:
ALARM2(0) = Loss of Signal in Macro 2
ALARM2(1) = Loss of Frame in Macro 2
ALARM2(2) = Loss of Pointer in Macro 2
ALARM2(3) = Path AIS in Macro 2
ALARM2(4) = Line AIS in Macro 2
ALARM2(0)
ALARM2(1)
ALARM2(2)
ALARM2(3)
ALARM2(4)
M01
M03
P01
P03
P05
O
O
O
O
O
LVTTL-5sd
LVTTL-5sd
LVTTL-5sd
Alarm Pins for Receive Macro 3:
The ALARM3(0:4) outputs are controlled real time by the same internal
control signals that also cause the corresponding microprocessor interrupt.
The alarm conditions that are output on these pins are as follows:
ALARM3(0) = Loss of Signal in Macro 3
ALARM3(1) = Loss of Frame in Macro 3
ALARM3(2) = Loss of Pointer in Macro 3
ALARM3(3) = Path AIS in Macro 3
ALARM3(4) = Line AIS in Macro 3
ALARM3(0)
ALARM3(1)
ALARM3(2)
ALARM3(3)
ALARM3(4)
T01
T03
T05
C05
E07
O
O
O
O
O
Alarm Pins for Receive Macro 4:
The ALARM4(0:4) outputs are controlled real time by the same internal
control signals that also cause the corresponding microprocessor interrupt.
The alarm conditions that are output on these pins are as follows:
ALARM4(0) = Loss of Signal in Macro 4
ALARM4(1) = Loss of Frame in Macro 4
ALARM4(2) = Loss of Pointer in Macro 4
ALARM4(3) = Path AIS in Macro 4
ALARM4(4) = Line AIS in Macro 4
ALARM4(0)
ALARM4(1)
ALARM4(2)
ALARM4(3)
ALARM4(4)
J11
L09
M10
N09
P10
O
O
O
O
O
Pin Information
ssframer.01
8/27/99
Page 48 of 279
