I2C
11.2 I
2
C AC Electrical Specifications
provides the AC timing parameters for the I
2
C interface of the MPC8540.
Table 40. I
2
C AC Electrical Specifications
All values refer to V
IH
(min) and V
IL
(max) levels (see
Parameter
SCL clock frequency
Low period of the SCL clock
High period of the SCL clock
Setup time for a repeated START condition
Hold time (repeated) START condition (after this period, the
first clock pulse is generated)
Data setup time
Data hold time:
CBUS compatible masters
I
2
C bus devices
Set-up time for STOP condition
Bus free time between a STOP and START condition
Noise margin at the LOW level for each connected device
(including hysteresis)
Noise margin at the HIGH level for each connected device
(including hysteresis)
Symbol
1
f
I2C
t
I2CL 6
t
I2CH 6
t
I2SVKH 6
t
I2SXKL 6
t
I2DVKH 6
t
I2DXKL
Min
0
1.3
0.6
0.6
0.6
100
—
0
2
Max
400
—
—
—
—
—
—
0.9
3
—
—
—
—
Unit
kHz
μs
μs
μs
μs
ns
μs
t
I2PVKH
t
I2KHDX
V
NL
V
NH
0.6
1.3
0.1
×
OV
DD
0.2
×
OV
DD
μs
μs
V
V
Notes:
1.The symbols used for timing specifications herein follow the pattern of t
(first two letters of functional block)(signal)(state)
(reference)(state)
for inputs and t
(first two letters of functional block)(reference)(state)(signal)(state)
for outputs. For example, t
I2DVKH
symbolizes I
2
C timing (I2) with respect to the time data input signals (D) reach the valid state (V) relative to the t
I2C
clock reference (K) going to the high (H) state or setup time. Also, t
I2SXKL
symbolizes I
2
C timing (I2) for the time that
the data with respect to the start condition (S) went invalid (X) relative to the t
I2C
clock reference (K) going to the low
(L) state or hold time. Also, t
I2PVKH
symbolizes I
2
C timing (I2) for the time that the data with respect to the stop
condition (P) reaching the valid state (V) relative to the t
I2C
clock reference (K) going to the high (H) state or setup
time. For rise and fall times, the latter convention is used with the appropriate letter: R (rise) or F (fall).
2.MPC8540 provides a hold time of at least 300 ns for the SDA signal (referred to the V
IHmin
of the SCL signal) to bridge
the undefined region of the falling edge of SCL.
3.The maximum t
I2DVKH
has only to be met if the device does not stretch the LOW period (t
I2CL
) of the SCL signal.
4.C
B
= capacitance of one bus line in pF.
6.Guaranteed by design.
provides the AC test load for the I
2
C.
Output
Z
0
= 50
Ω
R
L
= 50
Ω
OV
DD
/2
Figure 29. I
2
C AC Test Load
