PCI/PCI-X
Notes
Table 43. PCI-X AC Timing Specifications at 66 MHz (continued)
Parameter
Symbol
Min
Max
Unit
PCI-X initialization pattern to HRESET setup time
HRESET to PCI-X initialization pattern hold time
Notes:
t
10
0
clocks
ns
11
PCIVRH
tPCRHIX
50
6, 11
1.See the timing measurement conditions in the PCI-X 1.0a Specification.
2.Minimum times are measured at the package pin (not the test point). Maximum times are measured with the test point and
load circuit.
3.Setup time for point-to-point signals applies to REQ and GNT only. All other signals are bused.
4.For purposes of active/float timing measurements, the Hi-Z or off state is defined to be when the total current delivered
through the component pin is less than or equal to the leakage current specification.
5.Setup time applies only when the device is not driving the pin. Devices cannot drive and receive signals at the same time.
6.Maximum value is also limited by delay to the first transaction (time for HRESET high to first configuration access, tPCRHFV).
The PCI-X initialization pattern control signals after the rising edge of HRESET must be negated no later than two clocks
before the first FRAME and must be floated no later than one clock before FRAME is asserted.
7.A PCI-X device is permitted to have the minimum values shown for t
and tCYC only in PCI-X mode. In conventional
PCKHOV
mode, the device must meet the requirements specified in PCI 2.2 for the appropriate clock frequency.
8.Device must meet this specification independent of how many outputs switch simultaneously.
9.The timing parameter tPCRHFV is a minimum of 10 clocks rather than the minimum of 5 clocks in the PCI-X 1.0a Specification.
10.Guaranteed by characterization.
11.Guaranteed by design.
Table 44 provides the PCI-X AC timing specifications at 133 MHz.
Table 44. PCI-X AC Timing Specifications at 133 MHz
Parameter
SYSCLK to signal valid delay
Symbol
Min
Max
Unit
Notes
t
3.8
ns
1, 2, 3,
7, 8
PCKHOV
Output hold from SYSCLK
tPCKHOX
tPCKHOZ
0.7
7
ns
ns
1, 11
SYSCLK to output high impedance
1, 4, 8,
12
Input setup time to SYSCLK
tPCIVKH
1.4
ns
3, 5, 9,
11
Input hold time from SYSCLK
tPCIXKH
tPCRVRH
tPCRHRX
tPCRHFV
0.5
10
0
50
ns
11
12
REQ64 to HRESET setup time
clocks
ns
HRESET to REQ64 hold time
12
HRESET high to first FRAME assertion
PCI-X initialization pattern to HRESET setup time
10
10
clocks
clocks
10, 12
12
t
PCIVRH
MPC8540 Integrated Processor Hardware Specifications, Rev. 4
Freescale Semiconductor
53
