A49FL004
Table 12: Product Identification
Description
Address
Data
00000h
00003h
37h
7Fh
Manufacturer ID
Device ID
A49FL004
00001h
99h
Figure 8: System Memory Map and Device Memory Map for A49FL004
System M em ory
(Top 4M B ytes)
A 49FL004
D evice M em ory
07FFFF
FFFFFFFFh
B lock
7
TB L
(64K B ytes)
070000
06FFFF
B lock
6
(64K B ytes)
060000
05FFFF
B lock
5
(64K B ytes)
050000
04FFFF
B lock
4
(64K B ytes)
040000
03FFFF
B lock
3
W P
(64K B ytes)
for B lock
6 ~ 0
030000
02FFFF
B lock
2
(64K B ytes)
020000
01FFFF
B lock
1
(64K B ytes)
010000
00FFFF
B lock
0
(64K B ytes)
FFF80000h
000000
R ange for
A dditional FW H D evices
FFC 0000h
PRELIMINARY
(September, 2005, Version 0.0)
17
