A49FL004
DC and AC Operating Range
Range
A49FL004
Operating Temperature
VDD Power Supply
0°C to +70°C
3.0V –3.6V
Table 15: DC Operating Characteristics
Limits
Typ
Parameter
Test Conditions
Symbol
Min
Max
15
Units
mA
VCC Active Read Current
FWH4 or LFRAME = VIL, f = 33MHz,
IOUT = 0mA, VDD = VDD Max
ICC1
2
7
(FWH/LPC)
(2)
ICC2
VCC Program/Erase Current
20
mA
Standby VCC Current
(FWH/LPC Mode)
FWH4 or LFRAME = VIH, f = 33MHz,
VDD = VDD Max
ISB
IRY
II
500
10
µA
mA
µA
Ready Mode VCC Current
(FWH/LPC Mode)
FWH4 or LFRAME = VIL, f = 33MHz,
IOUT = 0mA, VDD = VDD Max
Input Leakage Current for IC,
ID[3:0] Pins
VIN = 0V to VDD, VDD = VDD Max
100
ILI
ILO
Input Leakage Current
Output Leakage Current
Input High Voltage
±1
µA
µA
V
VIN = 0V to VDD, VDD = VDD Max
VI/O = 0V to VDD, VDD = VDD Max
±1
VIH
VIL
0.7VDD
VDD+0.5
0.3VDD
0.1VDD
Input Low Voltage
-0.5
V
VOL
VOH
Output Low Voltage
Output High Voltage
V
IOL= 2.0mA, VDD = VDD Min
IOH = -100µA, VDD = VDD Min
0.9VDD
V
Notes:
1. Characterized but not 100％ tested.
Table 16: Pin Impedance (VDD=3.3V, T=25°C, f=1MHz)
Description
Test Condition
Max
Parameter
(1)
CI/O
I/O Pin Capacitance
Input Capacitance
Pin Inductance
VI/O = 0V
VIN = 0V
12pF
12pF
20nH
(1)
CIN
(2)
LPIN
Notes:
1. These parameters are characterized but not 100％ tested.
2. Refer to PCI specification.
Table 17: FWH/LPC Interface Clock Characteristics
Parameter
Min
Max
Units
Symbol
tCYC
tHIGH
tLOW
CLK Cycle Time
30
11
11
1
ns
ns
CLK High Time
CLK Low Time
ns
CLK Slew Rate (peak-to-peak)
INIT or RST Slew Rate
4
V/ns
mV/ns
50
PRELIMINARY
(September, 2005, Version 0.0)
20
AMIC Technology, Corp.
