A49FL004
Table 13: Sector/Block Address Table
Block Size
(Kbytes)
Sector Size
(K bytes)
Sector Number
Hardware
Block
Sector
Address Range
127
126
7F000h - 7FFFFh
7E000h – 7EFFFh
7D000h – 7DFFFh
7C000h – 7CFFFh
7B000h – 7BFFFh
7A000h – 7AFFFh
79000h – 79FFFh
78000h – 78FFFh
77000h – 77FFFh
76000h – 76FFFh
75000h – 75FFFh
74000h – 74FFFh
73000h - 73FFFh
72000h – 72FFFh
71000h – 71FFFh
70000h - 70FFFh
60000h - 6FFFFh
50000h - 5FFFFh
40000h - 4FFFFh
30000h - 3FFFFh
20000h - 2FFFFh
10000h - 1FFFFh
00000h - 0FFFFh
125
124
123
122
121
120
Block 7(Boot Block)
64
16
4 Kbytes/Sector
TBL
119
118
117
116
115
114
113
112
Block 6
Block 5
Block 4
Block 3
Block 2
Block 1
Block 0
64
64
64
64
64
64
64
16
16
16
16
16
16
16
4 Kbytes/Sector
4 Kbytes/Sector
4 Kbytes/Sector
4 Kbytes/Sector
4 Kbytes/Sector
4 Kbytes/Sector
4 Kbytes/Sector
111 - 96
95 - 80
79 - 64
63 - 48
47 - 32
31 -16
15 - 0
WP
PRELIMINARY
(September, 2005, Version 0.0)
