Arria GX Architecture
Enhanced PLLs
Arria GX devices contain up to four enhanced PLLs with advanced clock
management features. These features include support for external clock
feedback mode, spread-spectrum clocking, and counter cascading.
Figure 2–65 shows a diagram of the enhanced PLL.
Figure 2–65. Arria GX Enhanced PLL Note (1)
From Adjacent PLL
Post-Scale
V
Phase Selection
CO
Selectable at Each
PLL Output Port
Counters
Clock
Switchover
Circuitry
Spread
Spectrum
/c0
/c1
/c2
Phase Frequency
Detector
INCLK[3..0]
4
4
8
6
Global
Clocks
/n
8
Charge
Pump
Loop
Filter
PFD
VCO
6
Regional
Clocks
Global or
Regional
Clock
/c3
/c4
/c5
I/O Buffers
(3)
/m
(2)
to I/O or general
routing
Lock Detect
& Filter
FBIN
VCO Phase Selection
Affecting All Outputs
Shaded Portions of the
PLL are Reconfigurable
Notes to Figure 2–65:
(1) Each clock source can come from any of the four clock pins that are physically located on the same side of the device
as the PLL.
(2) If the feedback input is used, you will lose one (or two, if FBIN is differential) external clock output pin.
(3) Each enhanced PLL has three differential external clock outputs or six single-ended external clock outputs.
(4) The global or regional clock input can be driven by an output from another PLL, a pin-driven dedicated global or
regional clock, or through a clock control block provided the clock control block is fed by an output from another
PLL or a pin-driven dedicated global or regional clock. An internally generated global signal cannot drive the PLL.
Fast PLLs
Arria GX devices contain up to four fast PLLs with high-speed serial
interfacing ability. Fast PLLs offer high-speed outputs to manage the
high-speed differential I/O interfaces. Figure 2–66 shows a diagram of
the fast PLL.
