[AK4679]
3. EXT Slave Mode
Example:
Audio I/F Format: MSB justified (ADC and DAC)
Input MCKI frequency: 256fs
Sampling Frequency: 44.1kHz
Power Supply
(1)
(1) Power Supply & PDN pin = “L” Æ “H”
PDNA pin
(2)
(3)
PMVCM bit
(2)Addr:00H, Data:00H
Addr:03H, Data:F0H
Addr:04H, Data:00H
Addr:05H, Data:02H
(Addr:00H, D0)
(4)
(4)
MCKI pin
Input
Input
LRCK pin
BICK pin
(3) Addr:00H, Data:01H
MCKI, BICK and LRCK input
Figure 151. Clock Set Up Sequence (3)
<Example>
(1) After Power Up, PDNA pin = “L” Æ “H”.
“L” time of 1.5μs or more is needed to reset the AK4679.
(2) Dummy command (Addr:00H, Data:00H) must be executed before control register is set.
DIF1-0, CM1-0 and FS3-0 bits should be set during this period.
(3) Power Up VCOM: PMVCM bit = “0” Æ “1”
VCOM should first be powered up before the other block operates. Rise-up time of the VCOM pin is 1.5ms
(max) when the external capacitance is 1μF.
(4) Normal operation starts after the MCKI, LRCK and BICK are supplied.
MS1402-E-06
2013/02
- 207 -
