INTERRUPTS (Cont’d)
Figure 15. Interrupt Processing Flowchart
FROM RESET
N
I BIT SET?
N
Y
INTERRUPT
PENDING?
Y
FETCH NEXT INSTRUCTION
N
IRET?
STACK PC, X, A, CC
SET I BIT
Y
LOAD PC FROM INTERRUPT VECTOR
EXECUTE INSTRUCTION
RESTORE PC, X, A, CC FROM STACK
THIS CLEARS I BIT BY DEFAULT
