a-Si TFT LCD Single Chip Driver
240RGBx320 Resolution and 262K color
ILI9325
according to the factor respectively. See “Resizing function”.
RCH[1:0] Sets the number of remainder pixels in horizontal direction when resizing a picture.
By specifying the number of remainder pixels by RCH bits, the data can be transferred without
taking the reminder pixels into consideration. Make sure that RCH = 2’h0 when not using the
resizing function (RSZ = 2’h0) or there are no remainder pixels.
RCV[1:0] Sets the number of remainder pixels in vertical direction when resizing a picture.
By specifying the number of remainder pixels by RCV bits, the data can be transferred without
taking the reminder pixels into consideration. Make sure that RCV = 2’h0 when not using the
resizing function (RSZ = 2’h0) or there are no remainder pixels.
RSZ[1:0]
Resizing factor
No resizing (x1)
x 1/2
Setting prohibited
x 1/4
00
01
10
11
RCH[1:0]
Number of remainder Pixels in Horizontal Direction
00
01
10
11
0 pixel*
1 pixel
2 pixel
3 pixel
RCV[1:0]
Number of remainder Pixels in Vertical Direction
00
01
10
11
0 pixel*
1 pixel
2 pixel
3 pixel
*1 pixel = 1RGB
8.2.7. Display Control 1 (R07h)
R/W RS
D15 D14
D13
D12
D11 D10 D9
D8
D7 D6
D5
D4 D3 D2 D1 D0
W
1
0
0
PTDE1 PTDE0
0
0
0
BASEE
0
0
GON DTE CL
0
D1
D0
D[1:0] Set D[1:0]=”11” to turn on the display panel, and D[1:0]=”00” to turn off the display panel.
A graphics display is turned on the panel when writing D1 = “1”, and is turned off when writing
D1 = “0”.
When writing D1 = “0”, the graphics display data is retained in the internal GRAM and the
ILI9325 displays the data when writing D1 = “1”. When D1 = “0”, i.e. while no display is shown on the
panel, all source outputs becomes the GND level to reduce charging/discharging current, which is
generated within the LCD while driving liquid crystal with AC voltage.
When the display is turned off by setting D[1:0] = “01”, the ILI9325 continues internal display
operation. When the display is turned off by setting D[1:0] = “00”, the ILI9325 internal display
operation is halted completely. In combination with the GON, DTE setting, the D[1:0] setting controls
display ON/OFF.
The information contained herein is the exclusive property of ILI Technology Corp. and shall not be distributed,
reproduced, or disclosed in whole or in part without prior written permission of ILI Technology Corp.
Page 59 of 111
Version: 0.35
