Proprietary TranSwitch Corporation Information for use Solely by its Customers
L3M
TXC-03452B
DATA SHEET
Figure 29. Boundary Scan Timing
tPWL
tPWH
TCK
(Input)
tH(1)
tSU(1)
TMS
(Input)
tH(2)
tSU(2)
TDI
(Input)
tD
TDO
(Output)
Parameter
Symbol
Min
Max
Unit
TCK clock high time
tPWH
tPWL
tSU(1)
tH(1)
tSU(2)
tH(2)
tD
50
50
3.0
5.0
6.0
5.0
-
ns
ns
ns
ns
ns
ns
ns
TCK clock low time
TMS setup time to TCK↑
TMS hold time after TCK↑
TDI setup time to TCK↑
TDI hold time after TCK↑
-
-
-
-
TDO output delay after TCK↓
10
TXC-03452B-MB
Ed. 6, April 2001
- 48 of 96 -
