APEX 20K Programmable Logic Device Family Data Sheet
APEX 20K devices include device enhancements to support the SignalTap
embedded logic analyzer. By including this circuitry, the APEX 20K
device provides the ability to monitor design operation over a period of
time through the IEEE Std. 1149.1 (JTAG) circuitry; a designer can analyze
internal logic at speed without bringing internal signals to the I/ O pins.
This feature is particularly important for advanced packages such as
FineLine BGA packages because adding a connection to a pin during the
debugging process can be difficult after a board is designed and
manufactured.
SignalTap
Embedded
Logic Analyzer
All APEX 20K devices provide JTAG BST circuitry that complies with the
IEEE Std. 1149.1-1990 specification. The EP20K1500E device supports the
JTAG BYPASS instruction and the SignalTap instructions. JTAG
boundary-scan testing can be performed before or after configuration, but
not during configuration. APEX 20K devices can also use the JTAG port
for configuration with the Quartus II software or with hardware using
either Jam Files (.jam) or Jam Byte-Code Files (.jbc). Finally, APEX 20K
devices (except the EP20K1500E) use the JTAG port to monitor the logic
operation of the device with the SignalTap embedded logic analyzer.
APEX 20K devices support the JTAG instructions shown in Table 19.
IEEE Std.
1149.1 (JTAG)
Boundary-Scan
Support
Table 19. APEX 20K JTAG Instructions
JTAG Instruction
Description
SAMPLE/PRELOAD
EXTEST
Allows a snapshot of signals at the device pins to be captured and examined during
normal device operation, and permits an initial data pattern to be output at the device
pins. Also used by the SignalTap embedded logic analyzer.
Allows the external circuitry and board-level interconnections to be tested by forcing a
test pattern at the output pins and capturing test results at the input pins.
BYPASS
Places the 1-bit bypass register between the TDIand TDOpins, which allows the BST
data to pass synchronously through selected devices to adjacent devices during
normal device operation.
(1)
USERCODE
IDCODE
Selects the 32-bit USERCODE register and places it between the TDIand TDOpins,
allowing the USERCODE to be serially shifted out of TDO.
Selects the IDCODE register and places it between TDIand TDO, allowing the
IDCODE to be serially shifted out of TDO.
ICR Instructions
Used when configuring an APEX 20K device via the JTAG port with a MasterBlasterTM
or ByteBlasterMVTM download cable, or when using a Jam File or Jam Byte-Code File
via an embedded processor.
SignalTap Instructions
Monitors internal device operation with the SignalTap embedded logic analyzer.
(1)
Note:
(1) The EP20K1500E device supports the JTAG BYPASS instruction and the SignalTap instructions.
Altera Corporation
55
