TrueSpeech® Co-Processor
PRELIMINARY/CONFIDENTIAL
Version: 1.18
10.8
DMA Read from Host Receive Data Buffer Access Port (Single Cycle Mode)
HSTCSN
t1
t2
RXDREQ
RXDACKN
HSTRDN
HSTDB7-0
RX Ready
Buffer Address
IRQN
t4
t3
byte 1
byte 2
byte 2N
Parameter
Description
Min
Max
3 * MAINCLOCKP
t1
RXDACKN asserted to RXDREQ
de-asserted response time
t2
t3
RXDREQ re-assertion delay
RXDACKN setup before falling
edge of HSTRDN
16 * MAINCLOCKP
5 ns
t4
RXDACKN hold time after rising
edge of HSTRDN
2 ns
168
