Secondary Registers for Test and De-Bugging MT312
10.2.51 QPSK Test State. Register 106 (R/W)
QPSK TEST ST (106)
Default value
0 dec.
00 hex.
QPSK TEST ST[7:0]
For factory test purposes only.
10.2.52 Test Mode. Register 125 (R/W)
TEST MODE (125)
Default value
0 dec.
00 hex.
TEST MODE[7:0]:
This register is for testing purposes only.
10.3 Read only Secondary Register Map
Writing to these registers will have no effect.
Def
hex
NAME
ADR
B7
B6
B5
B4
B3
B2
B1
B0
TEST R
107
TEST R[7:0] Test Read, for test purposes only.
R
00
10.4 Secondary Registers for Test and De-Bugging Read Register
10.4.1 Test Read. Register 107 (R)
TEST R (107) Default value0 dec.00 hex.
TEST R[7:0]For test purposes only.
