Le58083
Data Sheet
ABSOLUTE MAXIMUM RATINGS
Stresses above those listed under Absolute Maximum Ratings can cause permanent device failure. Functionality at or above
these limits is not implied. Exposure to absolute maximum ratings for extended periods can affect device reliability.
–60° C < TA < +125° C
–40° C < TA < +85° C
5 to 95%
Storage Temperature
Ambient Temperature, under Bias
Ambient relative humidity (non condensing)
VCCA with respect to AGND
–0.4 to + 4.0 V
VCCA with respect to VCCD
±0.4 V
V
V
CCD with respect to DGND
IN with respect to AGND
–0.4 to + 4.0 V
–0.4 V to (VCCA + 0.4 V)
AGND with respect to DGND
±50 mV
Digital pins with respect to DGND
Total combined CD1–C7 current for each four-channel group:
Source from VCCD
–0.4 to 5.5 V or VCCD + 2.37 V, whichever is smaller
40 mA
40 mA
± 100 mA
1.0 A
Sink into DGND
Latch up immunity (any pin)
Total VCC current if rise rate of VCC > 0.4 V/µs
Package Assembly
The green package devices are assembled with enhanced environmental, compatible lead-free, halogen-free, and antimony-free
materials. The leads possess a matte-tin plating which is compatible with conventional board assembly processes or newer lead-
free board assembly processes. The peak soldering temperature should not exceed 245°C during printed circuit board assembly.
Refer to IPC/JEDEC J-Std-020B Table 5-2 for the recommended solder reflow temperature profile.
OPERATING RANGES
Zarlink guarantees the performance of this device over commercial (0º C to 70º C) and industrial (−40º C to 85º C) temperature
ranges by conducting electrical characterization over each range and by conducting a production test with single insertion
coupled to periodic sampling. These characterization and test procedures comply with section 4.6.2 of Bellcore GR-357-CORE
Component Reliability Assurance Requirements for Telecommunications Equipment
Environmental Ranges
−40° C < TA < +85° C
Ambient Temperature
Ambient Relative Humidity
15 to 85%
Electrical Ranges
+3.3 V ± 5%
VCCD ± 50 mV
Analog Supply VCCA
Digital Supply VCCD
DGND
+3.3 V ± 5%
0 V
AGND
±10 mV
0.1 µF ± 20%
DGND to +5.25 V
CFIL Capacitance: VREF_X to AGND
Digital Pins
12
