Figure 5 Tracking module block diagram
The indvidual sub-blocks in the tracking modules are:
Carrier DCO
The Carrier DCO, which is clocked at the SAMPCLK
frequency, is used to synthesise the digital local oscillator signal
required to bring the input signal to baseband in the mixer
block, and must be adjusted away from its nominal value to
allow for Doppler shift and reference frequency error.
When used with the GP2015/GP2010 the nominal
frequency of this signal is 1·405396825 MHz (with a
resolution of 42·57475mHz) and is set by loading the 26-
bit register CHx_CARRIER_DCO_INCR. This very fine
resolution is required so that the DCO will stay in phase
with the satellite signal for an adequate time. The Carrier
DCO Phase cannot be directly set, but must be adjusted
by altering the frequency.
The Carrier DCO outputs are 4-level, 8-phase sinusoids
with the sequences over one cycle as shown in Table 4.
Destination Arm
I
LO
Q
LO
Sequence
21 11 12 12 11 21 22 22
12 12 11 21 22 22 21 11
Table 4 Carrier DCO outputs
As the clock to the DCO is normally less than 8 times the
output frequency, not all phases are generated in every
cycle. With a typical clock frequency of 5·714 MHz and an
output frequency of 1·405 MHz there are only about
4 phases per cycle. These will slide through the cycle as
time progresses to cover all values.
Code DCO
The Code DCO is similar to the Carrier DCO block. It is
also clocked at the SAMPCLK frequency and synthesises
the oscillator required to drive the code generator at twice
the required chipping rate. The nominal frequency of the
output is 2·046 MHz, to give a chip rate of 1·023 MHz and
is
set
by
loading
the
25-bit
register
CHx_CODE_DCO_INCR.
It is programmed with a resolution of 85·14949 mHz when
used with a GP2015/GP2010 front end. Again, the very
fine resolution is needed to keep the DCO in phase with
the satellite signal. The Code DCO Phase can only be set
to the exact satellite phase in Preset mode. In Update
mode, it must be aligned with the satellite phase by
adjusting its frequency.
9
