Spartan-3E FPGA Family: DC and Switching Characteristics
I/O Timing
Table 86: Pin-to-Pin Clock-to-Output Times for the IOB Output Path
Speed Grade
Symbol
Description
Conditions
Device
-5
-4
Units
Max(2)
Max(2)
Clock-to-Output Times
TICKOFDCM
When reading from the Output Flip-Flop
LVCMOS25(3), 12 mA
XC3S100E
XC3S250E
XC3S500E
XC3S1200E
XC3S1600E
XC3S100E
XC3S250E
XC3S500E
XC3S1200E
XC3S1600E
2.66
3.00
3.01
3.01
3.00
5.60
4.91
4.98
5.36
5.45
2.79
3.45
3.46
3.46
3.45
5.92
5.43
5.51
5.94
6.05
ns
ns
ns
ns
ns
ns
ns
ns
ns
ns
(OFF), the time from the active transition output drive, Fast slew
on the Global Clock pin to data appearing rate, with DCM(4)
at the Output pin. The DCM is used.
TICKOF
When reading from OFF, the time from the LVCMOS25(3), 12 mA
active transition on the Global Clock pin to output drive, Fast slew
data appearing at the Output pin. The
DCM is not used.
rate, without DCM
Notes:
1. The numbers in this table are tested using the methodology presented in Table 95 and are based on the operating conditions set forth in
Table 77 and Table 80.
2. For minimums, use the values reported by the Xilinx timing analyzer.
3. This clock-to-output time requires adjustment whenever a signal standard other than LVCMOS25 is assigned to the Global Clock Input or a
standard other than LVCMOS25 with 12 mA drive and Fast slew rate is assigned to the data Output. If the former is true, add the appropriate
Input adjustment from Table 91. If the latter is true, add the appropriate Output adjustment from Table 94.
4. DCM output jitter is included in all measurements.
DS312 (v4.2) December 14, 2018
www.xilinx.com
Product Specification
125
