TPS929160-Q1
ZHCSNG0 – APRIL 2023
www.ti.com.cn
Return to the Summary Table.
图 7-98. DIAGEN0 Register
7
6
5
4
3
2
1
0
RESERVED
R-0h
DIAGENOUTB1 DIAGENOUTB0
R/W-X R/W-X
RESERVED
R-0h
DIAGENOUTA1 DIAGENOUTA0
R/W-X R/W-X
表 7-102. DIAGEN0 Register Field Descriptions
Bit
Field
Type
Reset
Description
7-6
5
RESERVED
R
0h
Reserved
DIAGENOUTB1
R/W
X
Diagnostics enable register for OUTB1
Load EEPROM data when reset
0h = Disabled
1h = Enabled
4
DIAGENOUTB0
R/W
X
Diagnostics enable register for OUTB0
Load EEPROM data when reset
0h = Disabled
1h = Enabled
3-2
1
RESERVED
R
0h
X
Reserved
DIAGENOUTA1
R/W
Diagnostics enable register for OUTA1
Load EEPROM data when reset
0h = Disabled
1h = Enabled
0
DIAGENOUTA0
R/W
X
Diagnostics enable register for OUTA0
Load EEPROM data when reset
0h = Disabled
1h = Enabled
7.6.3.2 DIAGEN1 Register (Offset = 71h) [Reset = X]
DIAGEN1 is shown in 图 7-99 and described in 表 7-103.
Return to the Summary Table.
图 7-99. DIAGEN1 Register
7
6
5
4
3
2
1
DIAGENOUTC1 DIAGENOUTC0
R/W-X R/W-X
0
RESERVED
R-0h
DIAGENOUTD1 DIAGENOUTD0
R/W-X R/W-X
RESERVED
R-0h
表 7-103. DIAGEN1 Register Field Descriptions
Bit
Field
Type
Reset
Description
7-6
5
RESERVED
R
0h
Reserved
DIAGENOUTD1
R/W
X
Diagnostics enable register for OUTD1
Load EEPROM data when reset
0h = Disabled
1h = Enabled
4
DIAGENOUTD0
R/W
X
Diagnostics enable register for OUTD0
Load EEPROM data when reset
0h = Disabled
1h = Enabled
3-2
1
RESERVED
R
0h
X
Reserved
DIAGENOUTC1
R/W
Diagnostics enable register for OUTC1
Load EEPROM data when reset
0h = Disabled
1h = Enabled
