表 7-105. DIAGEN3 Register Field Descriptions (continued)
Bit
Field
Type
Reset
Description
5
DIAGENOUTH1
R/W
X
Diagnostics enable register for OUTH1
Load EEPROM data when reset
0h = Disabled
1h = Enabled
4
DIAGENOUTH0
R/W
X
Diagnostics enable register for OUTH0
Load EEPROM data when reset
0h = Disabled
1h = Enabled
3-2
1
RESERVED
R
0h
X
Reserved
DIAGENOUTG1
R/W
Diagnostics enable register for OUTG1
Load EEPROM data when reset
0h = Disabled
1h = Enabled
0
DIAGENOUTG0
R/W
X
Diagnostics enable register for OUTG0
Load EEPROM data when reset
0h = Disabled
1h = Enabled
7.6.3.5 SLSTHSEL0 Register (Offset = 74h) [Reset = X]
SLSTHSEL0 is shown in 图 7-102 and described in 表 7-106.
Return to the Summary Table.
图 7-102. SLSTHSEL0 Register
7
6
5
4
3
2
1
0
RESERVED
R-0h
SLSTHOUTB1 SLSTHOUTB0
R/W-X R/W-X
RESERVED
R-0h
SLSTHOUTA1 SLSTHOUTA0
R/W-X R/W-X
表 7-106. SLSTHSEL0 Register Field Descriptions
Bit
Field
Type
Reset
Description
7-6
5
RESERVED
R
0h
Reserved
SLSTHOUTB1
R/W
X
Single-LED short-circuit threshold selection register for OUTB1
Load EEPROM data when reset
0h = SLSTH0 is selected
1h = SLSTH1 is selected
4
SLSTHOUTB0
R/W
X
Single-LED short-circuit threshold selection register for OUTB0
Load EEPROM data when reset
0h = SLSTH0 is selected
1h = SLSTH1 is selected
3-2
1
RESERVED
R
0h
X
Reserved
SLSTHOUTA1
R/W
Single-LED short-circuit threshold selection register for OUTA1
Load EEPROM data when reset
0h = SLSTH0 is selected
1h = SLSTH1 is selected
0
SLSTHOUTA0
R/W
X
Single-LED short-circuit threshold selection register for OUTA0
Load EEPROM data when reset
0h = SLSTH0 is selected
1h = SLSTH1 is selected
7.6.3.6 SLSTHSEL1 Register (Offset = 75h) [Reset = X]
SLSTHSEL1 is shown in 图 7-103 and described in 表 7-107.
Return to the Summary Table.
