TPS929160-Q1
ZHCSNG0 – APRIL 2023
www.ti.com.cn
图 7-103. SLSTHSEL1 Register
7
6
5
4
3
2
1
0
RESERVED
SLSTHOUTD1 SLSTHOUTD0
R/W-X R/W-X
RESERVED
R-0h
SLSTHOUTC1 SLSTHOUTC0
R/W-X R/W-X
R-0h
表 7-107. SLSTHSEL1 Register Field Descriptions
Bit
7-6
5
Field
Type
Reset
Description
RESERVED
R
0h
Reserved
SLSTHOUTD1
R/W
X
Single-LED short-circuit threshold selection register for OUTD1
Load EEPROM data when reset
0h = SLSTH0 is selected
1h = SLSTH1 is selected
4
SLSTHOUTD0
R/W
X
Single-LED short-circuit threshold selection register for OUTD0
Load EEPROM data when reset
0h = SLSTH0 is selected
1h = SLSTH1 is selected
3-2
1
RESERVED
R
0h
X
Reserved
SLSTHOUTC1
R/W
Single-LED short-circuit threshold selection register for OUTC1
Load EEPROM data when reset
0h = SLSTH0 is selected
1h = SLSTH1 is selected
0
SLSTHOUTC0
R/W
X
Single-LED short-circuit threshold selection register for OUTC0
Load EEPROM data when reset
0h = SLSTH0 is selected
1h = SLSTH1 is selected
7.6.3.7 SLSTHSEL2 Register (Offset = 76h) [Reset = X]
SLSTHSEL2 is shown in 图 7-104 and described in 表 7-108.
Return to the Summary Table.
图 7-104. SLSTHSEL2 Register
7
6
5
4
3
2
1
0
RESERVED
R-0h
SLSTHOUTF1 SLSTHOUTF0
R/W-X R/W-X
RESERVED
R-0h
SLSTHOUTE1 SLSTHOUTE0
R/W-X R/W-X
表 7-108. SLSTHSEL2 Register Field Descriptions
Bit
Field
Type
Reset
Description
7-6
5
RESERVED
R
0h
Reserved
SLSTHOUTF1
R/W
X
Single-LED short-circuit threshold selection register for OUTF1
Load EEPROM data when reset
0h = SLSTH0 is selected
1h = SLSTH1 is selected
4
SLSTHOUTF0
R/W
X
Single-LED short-circuit threshold selection register for OUTF0
Load EEPROM data when reset
0h = SLSTH0 is selected
1h = SLSTH1 is selected
3-2
1
RESERVED
R
0h
X
Reserved
SLSTHOUTE1
R/W
Single-LED short-circuit threshold selection register for OUTE1
Load EEPROM data when reset
0h = SLSTH0 is selected
1h = SLSTH1 is selected
