表 7-108. SLSTHSEL2 Register Field Descriptions (continued)
Bit
Field
Type
Reset
Description
0
SLSTHOUTE0
R/W
X
Single-LED short-circuit threshold selection register for OUTE0
Load EEPROM data when reset
0h = SLSTH0 is selected
1h = SLSTH1 is selected
7.6.3.8 SLSTHSEL3 Register (Offset = 77h) [Reset = X]
SLSTHSEL3 is shown in 图 7-105 and described in 表 7-109.
Return to the Summary Table.
图 7-105. SLSTHSEL3 Register
7
6
5
4
3
2
1
0
RESERVED
R-0h
SLSTHOUTH1 SLSTHOUTH0
R/W-X R/W-X
RESERVED
R-0h
SLSTHOUTG1 SLSTHOUTG0
R/W-X R/W-X
表 7-109. SLSTHSEL3 Register Field Descriptions
Bit
Field
Type
Reset
Description
7-6
5
RESERVED
R
0h
Reserved
SLSTHOUTH1
R/W
X
Single-LED short-circuit threshold selection register for OUTH1
Load EEPROM data when reset
0h = SLSTH0 is selected
1h = SLSTH1 is selected
4
SLSTHOUTH0
R/W
X
Single-LED short-circuit threshold selection register for OUTH0
Load EEPROM data when reset
0h = SLSTH0 is selected
1h = SLSTH1 is selected
3-2
1
RESERVED
R
0h
X
Reserved
SLSTHOUTG1
R/W
Single-LED short-circuit threshold selection register for OUTG1
Load EEPROM data when reset
0h = SLSTH0 is selected
1h = SLSTH1 is selected
0
SLSTHOUTG0
R/W
X
Single-LED short-circuit threshold selection register for OUTG0
Load EEPROM data when reset
0h = SLSTH0 is selected
1h = SLSTH1 is selected
7.6.3.9 SLSDAC0 Register (Offset = 78h) [Reset = X]
SLSDAC0 is shown in 图 7-106 and described in 表 7-110.
Return to the Summary Table.
图 7-106. SLSDAC0 Register
7
6
5
4
3
2
1
0
SLSTH0
R/W-X
表 7-110. SLSDAC0 Register Field Descriptions
Bit
7-0
Field
Type
Reset
Description
SLSTH0
R/W
X
Single-LED short-circuit setting register for SLSTH0
Load EEPROM data when reset
V(SLSTH0) = SLSTH0*0.125V + 2.5V
