7.6.3 CONF Registers
表 7-100 lists the memory-mapped registers for the CONF registers. All register offset addresses not listed in 表
7-100 should be considered as reserved locations and the register contents should not be modified.
Configuration Register
表 7-100. CONF Registers
Offset
70h
71h
72h
73h
74h
75h
76h
77h
78h
79h
7Ah
7Bh
7Ch
7Dh
7Eh
7Fh
80h
81h
82h
83h
84h
85h
86h
87h
Acronym
DIAGEN0
DIAGEN1
DIAGEN2
DIAGEN3
SLSTHSEL0
SLSTHSEL1
SLSTHSEL2
SLSTHSEL3
SLSDAC0
SLSDAC1
REFERENCE
DIAG
Register Name
Section
Go
Go
Go
Go
Go
Go
Go
Go
Go
Go
Go
Go
Go
Go
Go
Go
Go
Go
Go
Go
Go
Go
Go
Go
OUTAn, OUTBn Diagnostics Enable Setting
OUTCn, OUTDn Diagnostics Enable Setting
OUTEn, OUTFn Diagnostics Enable Setting
OUTGn, OUTHn Diagnostics Enable Setting
OUTAn, OUTBn Single-LED Short Threshold Selecting
OUTCn, OUTDn Single-LED Short Threshold Selecting
OUTEn, OUTFn Single-LED Short Threshold Selecting
OUTGn, OUTHn Single-LED Short Threshold Selecting
Single-LED Short Threshold0 Setting
Single-LED Short Threshold1 Setting
Reference Setting
Diagnostics Setting
DIAGMASK
OUTMASK
DIM
Diagnostics Mask Setting
OUTXn Diagnostics Mask Setting
Dimming Parameter Setting
DIM-R
Reserved Register
FSMAP0
OUTAn, OUTBn Fail-safe Mapping Setting
OUTCn, OUTDn Fail-safe Mapping Setting
OUTEn, OUTFn Fail-safe Mapping Setting
OUTGn, OUTHn Fail-safe Mapping Setting
FlewWire Parameter Setting
FSMAP1
FSMAP2
FSMAP3
FLEXWIRE0
FLEXWIRE1
FLEXWIRE2
CRC
FlewWire Parameter Setting
FlewWire Parameter Setting
EEPROM CRC
Complex bit access types are encoded to fit into small table cells. 表 7-101 shows the codes that are used for
access types in this section.
表 7-101. CONF Access Type Codes
Access Type
Read Type
R
Code
Description
R
Read
Write Type
W
W
Write
Reset or Default Value
-n
Value after reset or the default
value
7.6.3.1 DIAGEN0 Register (Offset = 70h) [Reset = X]
DIAGEN0 is shown in 图 7-98 and described in 表 7-102.
