TMS320TCI6487
TMS320TCI6488
Communications Infrastructure Digital Signal Processor
www.ti.com
SPRS358F–APRIL 2007–REVISED AUGUST 2008
Table 8-45. EMAC Statistics Registers (continued)
HEX ADDRESS
02C8 0254
02C8 0258
02C8 025C
02C8 0260
02C8 0264
02C8 0268
02C8 026C
02C8 0270
02C8 0274
02C8 0278
02C8 027C
ACRONYM
TXEXCESSIVECOLL
TXLATECOLL
REGISTER NAME
Transmit Excessive Collision Frames Register
Transmit Late Collision Frames Register
TXUNDERRUN
TXCARRIERSENSE
TXOCTETS
Transmit Under Run Error Register
Transmit Carrier Sense Errors Register
Transmit Octet Frames Register
FRAME64
Transmit and Receive 64 Octet Frames Register
Transmit and Receive 65 to 127 Octet Frames Register
Transmit and Receive 128 to 255 Octet Frames Register
Transmit and Receive 256 to 511 Octet Frames Register
Transmit and Receive 512 to 1023 Octet Frames Register
FRAME65T127
FRAME128T255
FRAME256T511
FRAME512T1023
FRAME1024TUP
Transmit and Receive 1024 to 1518 Octet Frames
Register
02C8 0280
02C8 0284
02C8 0288
02C8 028C
NETOCTETS
Network Octet Frames Register
RXSOFOVERRUNS
RXMOFOVERRUNS
RXDMAOVERRUNS
Receive FIFO or DMA Start of Frame Overruns Register
Receive FIFO or DMA Middle of Frame Overruns Register
Receive DMA Start of Frame and Middle of Frame
Overruns Register
02C8 0290 - 02C8 02FC
-
Reserved
Table 8-46. EMAC Descriptor Memory
HEX ADDRESS
ACRONYM
REGISTER NAME
02E0 0000 - 02E0 3FFF
-
EMAC Descriptor Memory
Table 8-47. SGMII Control Registers
HEX ADDRESS
02C4 0000
ACRONYM
REGISTER NAME
Identification and Version register
IDVER
02C4 0004
SOFT_RESET
Software Reset Register
Control Register
02C4 0010
CONTROL
02C4 0014
STATUS
Status Register
02C4 0018
MR_ADV_ABILITY
Advertised Ability Register
Reserved
02C4 001C
-
02C4 0020
MR_LP_ADV_ABILITY
Link Partner Advertised Ability Register
Reserved
02C4 0024
-
02C4 0030
TX_CFG
RX_CFG
AUX_CFG
-
Transmit Configuration Register
Receive Configuration Register
Auxiliary Configuration Register
Reserved
02C4 0034
02C4 0038
02C4 0040 - 02C4 0048
Table 8-48. EMAC Interrupt Control (EMIC) Registers
HEX ADDRESS
02C8 1000
02C8 1004
02C8 1008
02C8 100C
02C8 1010
02C8 1014
02C8 1018
ACRONYM
IDVER
REGISTER NAME
Identification and Version register
SOFT_RESET
EM_CONTROL
INT_CONTROL
C_RX_THRESH_EN
C_RX_EN
Software Reset Register
Emulation Control Register
Interrupt Control Register
Core n Receive Threshold Interrupt Enable Register, n = 0, 1 and 2
Core n Receive Interrupt Enable Register, n = 0, 1 and 2
Core n Transmit Interrupt Enable Register, n = 0, 1 and 2
C_TX_EN
