Table 8-44. Ethernet MAC (EMAC) Control Registers (continued)
HEX ADDRESS
ACRONYM
REGISTER NAME
02C8 0660
RX0CP
Receive Channel 0 Completion Pointer (Interrupt Acknowledge)
Register
02C8 0664
02C8 0668
02C8 066C
02C8 0670
02C8 0674
02C8 0678
02C8 067C
RX1CP
RX2CP
RX3CP
RX4CP
RX5CP
RX6CP
RX7CP
Receive Channel 1 Completion Pointer (Interrupt Acknowledge)
Register
Receive Channel 2 Completion Pointer (Interrupt Acknowledge)
Register
Receive Channel 3 Completion Pointer (Interrupt Acknowledge)
Register
Receive Channel 4 Completion Pointer (Interrupt Acknowledge)
Register
Receive Channel 5 Completion Pointer (Interrupt Acknowledge)
Register
Receive Channel 6 Completion Pointer (Interrupt Acknowledge)
Register
Receive Channel 7 Completion Pointer (Interrupt Acknowledge)
Register
02C8 0680 - 02C8 06FC
02C8 0700 - 02C8 077C
02C8 0780 - 02C8 0FFF
-
-
-
Reserved
Reserved
Reserved
Table 8-45. EMAC Statistics Registers
HEX ADDRESS
02C8 0200
ACRONYM
REGISTER NAME
RXGOODFRAMES
RXBCASTFRAMES
Good Receive Frames Register
02C8 0204
Broadcast Receive Frames Register (Total number of
Good Broadcast Frames Receive)
02C8 0208
RXMCASTFRAMES
Multicast Receive Frames Register (Total number of Good
Multicast Frames Received)
02C8 020C
02C8 0210
RXPAUSEFRAMES
RXCRCERRORS
Pause Receive Frames Register
Receive CRC Errors Register (Total number of Frames
Received with CRC Errors)
02C8 0214
02C8 0218
02C8 021C
02C8 0220
RXALIGNCODEERRORS
RXOVERSIZED
Receive Alignment/Code Errors register (Total number of
frames Received with alignment/code errors)
Receive Oversized Frames Register (Total number of
Oversized Frames Received)
RXJABBER
Receive Jabber Frames Register (Total number of Jabber
Frames Received)
RXUNDERSIZED
Receive Undersized Frames Register (Total number of
Undersized Frames Received)
02C8 0224
02C8 0228
02C8 022C
02C8 0230
RXFRAGMENTS
RXFILTERED
Receive Frame Fragments Register
Filtered Receive Frames Register
Received QOS Filtered Frames Register
RXQOSFILTERERED
RXOCTETS
Receive Octet Frames Register (Total number of
Received Bytes in Good Frames)
02C8 0234
TXGOODFRAMES
Good Transmit Frames Register (Total number of Good
Frames Transmitted)
02C8 0238
02C8 023C
02C8 0240
02C8 0244
02C8 0248
02C8 024C
02C8 0250
TXBCASTFRAMES
TXMCASTFRAMES
TXPAUSEFRAMES
TXDEFERED
Broadcast Transmit Frames Register
Multicast Transmit Frames Register
Pause Transmit Frames Register
Deferred Transmit Frames Register
Transmit Collision Frames Register
Transmit Single Collision Frames Register
Transmit Multiple Collision Frames Register
TXCOLLISION
TXSINGLECOLL
TXMULTICOLL
