TMS320DM6437
Digital Media Processor
www.ti.com
SPRS345B–NOVEMBER 2006–REVISED MARCH 2007
Table 6-105. VLYNQ Registers (continued)
HEX ADDRESS RANGE
0x01E0 103C
ACRONYM
REGISTER NAME
VLYNQ Local Receive Address Map Offset 4 Register
VLYNQ Local Chip Version Register
VLYNQ Local Auto Negotiation Register
Reserved
RAMO4
0x01E0 1040
CHIPVER
0x01E0 1044
AUTNGO
0x01E0 1048
-
0x01E0 104C
-
Reserved
0x01E0 1050 - 0x01E0 105C
0x01E0 1060
-
Reserved
-
Reserved
01E0 10C00 0064
0x01E0 1068 - 0x01E0 107C
0x01E0 1080
-
Reserved
-
Reserved for future use
RREVID
RCTRL
RSTAT
RINTPRI
VLYNQ Remote Revision Register
VLYNQ Remote Control Register
VLYNQ Remote Status Register
VLYNQ Remote Interrupt Priority Vector Status/Clear Register
0x01E0 1084
0x01E0 1088
0x01E0 108C
0x01E0 1090
RINTSTATCLR VLYNQ Remote Unmasked Interrupt Status/Clear Register
RINTPENDSET VLYNQ Remote Interrupt Pending/Set Register
0x01E0 1094
0x01E0 1098
RINTPTR
RXAM
VLYNQ Remote Interrupt Pointer Register
0x01E0 109C
VLYNQ Remote Transmit Address Map Register
0x01E0 10A0
RRAMS1
RRAMO1
RRAMS2
RRAMO2
RRAMS3
RRAMO3
RRAMS4
RRAMO4
VLYNQ Remote Receive Address Map Size 1 Register
VLYNQ Remote Receive Address Map Offset 1 Register
VLYNQ Remote Receive Address Map Size 2 Register
VLYNQ Remote Receive Address Map Offset 2 Register
VLYNQ Remote Receive Address Map Size 3 Register
VLYNQ Remote Receive Address Map Offset 3 Register
VLYNQ Remote Receive Address Map Size 4 Register
VLYNQ Remote Receive Address Map Offset 4 Register
0x01E0 10A4
0x01E0 10A8
0x01E0 10AC
0x01E0 10B0
0x01E0 10B4
0x01E0 10B8
0x01E0 10BC
VLYNQ Remote Chip Version Register (values on the device_id and
device_rev pins of remote VLYNQ)
0x01E0 10C0
RCHIPVER
0x01E0 10C4
0x01E0 10C8
RAUTNGO
RMANNGO
RNGOSTAT
-
VLYNQ Remote Auto Negotiation Register
VLYNQ Remote Manual Negotiation Register
VLYNQ Remote Negotiation Status Register
Reserved
0x01E0 10CC
0x01E0 10D0 - 0x01E0 10DC
VLYNQ Remote Interrupt Vectors 3 - 0 (sourced from vlynq_int_i[3:0] port of
remote VLYNQ)
0x01E0 10E0
0x01E0 10E4
RINTVEC0
RINTVEC1
VLYNQ Remote Interrupt Vectors 7 - 4 (sourced from vlynq_int_i[7:4] port of
remote VLYNQ)
0x01E0 10E8 - 0x01E0 10FC
0x01E0 1100 - 0x01E0 1FFF
-
-
Reserved for future use
Reserved
