TMS320DM6437
Digital Media Processor
www.ti.com
SPRS345B–NOVEMBER 2006–REVISED MARCH 2007
Table 6-33. H3A Register Descriptions (continued)
0x01C7 1418
0x01C7 141C
0x01C7 1420
0x01C7 1424
0x01C7 1428
0x01C7 142C
0x01C7 1430
0x01C7 1434
0x01C7 1438
0x01C7 143C
0x01C7 1440
0x01C7 1444
0x01C7 1448
0x01C7 144C
0x01C7 1450
0x01C7 1454
0x01C7 1458
0x01C7 145C
AFBUFST
SDRAM/DDRAM Start Address for AF Engine
IIR Filter Coefficient Data for SET 0
IIR Filter Coefficient Data for SET 0
IIR Filter Coefficient Data for SET 0
IIR Filter Coefficient Data for SET 0
IIR Filter Coefficient Data for SET 0
IIR Filter Coefficient Data for SET 0
IIR Filter Coefficient Data for SET 1
IIR Filter Coefficient Data for SET 1
IIR Filter Coefficient Data for SET 1
IIR Filter Coefficient Data for SET 1
IIR Filter Coefficient Data for SET 1
IIR Filter Coefficient Data for SET 1
Configuration for AE/AWB Windows
Start Position for AE/AWB Windows
AFCOEF010
AFCOEF032
AFCOEFF054
AFCOEFF076
AFCOEFF098
AFCOEFF0010
AFCOEF110
AFCOEF132
AFCOEFF154
AFCOEFF176
AFCOEFF198
AFCOEFF1010
AEWWIN1
AEWINSTART
AEWINBLK
Start Position and Height for Black Line of AE/AWB Windows
Configuration for Subsample Data in AE/AWB Window
SDRAM/DDRAM Start Address for AE/AWB Engine
AEWSUBWIN
AEWBUFST
6.10.1.4.1 Auto Focus (AF) Engine
The following features are supported by the Auto Focus (AF) Engine.
•
•
•
•
•
•
•
•
•
•
Peak Mode in a Paxel (a Paxel is defined as a two dimensional block of pixels).
Accumulate the maximum Focus Value of each line in a Paxel
Accumulation/Sum Mode (instead of Peak mode).
Accumulate Focus Value in a Paxel.
Up to 36 Paxels in the horizontal direction and up to 128 Paxels in the vertical direction.
Programmable width and height for the Paxel. All paxels in the frame will be of same size.
Programmable red, green, and blue position within a 2x2 matrix.
Separate horizontal start for paxel and filtering.
Programmable vertical line increments within a paxel.
Parallel IIR filters configured in a dual-biquad configuration with individual coefficients (2 filters with 11
coefficients each). The filters are intended to compute the sharpness/peaks in the frame to focus on.
6.10.1.4.2 Auto Exposure (AE) and Auto White Balance (AWB) Engine
The following features are supported by the Auto Exposure (AE) and Auto White Balance (AWB) Engine.
•
•
•
•
•
Accumulate clipped pixels along with all non-saturated pixels.
Up to 36 horizontal windows.
Up to 128 vertical windows.
Programmable width and height for the windows. All windows in the frame will be of same size.
Separate vertical start coordinate and height for a black row of paxels that is different than the
remaining color paxels.
•
•
Programmable Horizontal Sampling Points in a window.
Programmable Vertical Sampling Points in a window.
