TMS320DM6437
Digital Media Processor
www.ti.com
SPRS345B–NOVEMBER 2006–REVISED MARCH 2007
Table 6-32. Resizer Register Descriptions (continued)
HEX ADDRESS RANGE
0x01C7 0C50
0x01C7 0C54
0x01C7 0C58
0x01C7 0C5C
0x01C7 0C60
0x01C7 0C64
0x01C7 0C68
0x01C7 0C6C
0x01C7 0C70
0x01C7 0C74
0x01C7 0C78
0x01C7 0C7C
0x01C7 0C80
0x01C7 0C84
0x01C7 0C88
0x01C7 0C8C
0x01C7 0C90
0x01C7 0C94
0x01C7 0C98
0x01C7 0C9C
0x01C7 0CA0
0x01C7 0CA4
0x01C7 0CA8
REGISTER ACRONYM
HFILT2120
DESCRIPTION
Horizontal Filter Coefficients 21 and 20
HFILT2322
HFILT2524
HFILT2726
HFILT2928
HFILT3130
VFILT10
Horizontal Filter Coefficients 23 and 22
Horizontal Filter Coefficients 25 and 24
Horizontal Filter Coefficients 27 and 26
Horizontal Filter Coefficients 29 and 28
Horizontal Filter Coefficients 31 and 30
Vertical Filter Coefficients 1 and 0
Vertical Filter Coefficients 3 and 2
Vertical Filter Coefficients 5 and 4
Vertical Filter Coefficients 7 and 6
Vertical Filter Coefficients 9 and 8
Vertical Filter Coefficients 11 and 10
Vertical Filter Coefficients 13 and 12
Vertical Filter Coefficients 15 and 14
Vertical Filter Coefficients 17 and 16
Vertical Filter Coefficients 19 and 18
Vertical Filter Coefficients 21 and 20
Vertical Filter Coefficients 23 and 22
Vertical Filter Coefficients 25 and 24
Vertical Filter Coefficients 27 and 26
Vertical Filter Coefficients 29 and 28
Vertical Filter Coefficients 31 and 30
Luminance Enhancer
VFILT32
VFILT54
VFILT76
VFILT98
VFILT1110
VFILT1312
VFILT1514
VFILT1716
VFILT1918
VFILT2120
VFILT2322
VFILT2524
VFILT2726
VFILT2928
VFILT3130
YENH
6.10.1.4 Hardware 3A (H3A)
The Hardware 3A (H3A) module provides control loops for Auto Focus, Auto White Balance and Auto
Exposure. There are 2 main components of the H3A module:
•
•
Auto Focus (AF) Engine
Auto Exposure (AE) & Auto White Balance (AWB) Engine
The AF engine extracts and filters the red, green, and blue data from the input image/video data and
provides either the accumulation or peaks of the data in a specified region. The specified region is a two
dimensional block of data and is referred to as a “paxel” for the case of AF.
The AE/AWB Engine accumulates the values and checks for saturated values in a sub sampling of the
video data. In the case of the AE/AWB, the two-dimensional block of data is referred to as a “window”.
The number, dimensions, and starting position of the AF paxels and the AE/AWB windows are separately
programmable.
The H3A register memory mapping is shown in Table 6-33.
Table 6-33. H3A Register Descriptions
HEX ADDRESS RANGE
0x01C7 1400
REGISTER ACRONYM
DESCRIPTION
Peripheral Revision and Class Information
Peripheral Control Register
PID
0x01C7 1404
PCR
0x01C7 1408
AFPAX1
Setup for the AF Engine Paxel Configuration
Setup for the AF Engine Paxel Configuration
Start Position for AF Engine Paxels
Start Position for IIRSH
0x01C7 140C
0x01C7 1410
AFPAX2
AFPAXSTART
AFIIRSH
0x01C7 1414
Submit Documentation Feedback
Peripheral Information and Electrical Specifications
219
