Table 6-12. Switching Characteristics Over Recommended Operating Conditions During Reset
(see Figure 6-8) (continued)
-400
-500
NO.
PARAMETER
-600
UNIT
MIN
MAX
0
8
9
td(RSTOUTH-V)
td(RSTOUTH-IV)
Delay time, RESETOUT high to pins valid
Delay time, RESETOUT high to pins invalid
ns
ns
12C
Figure 6-7 shows the Power-Up Timing. Figure 6-8 shows the Warm Reset (RESET) Timing. Max Reset
Timing is identical to Warm Reset Timing, except the boot and configuration pins are not relatched and
the BOOTCFG register retains its previous value latched before the Max Reset or System Reset were
initiated.
