3.7.3.13.3 EMIFA/VPSS Sub-Block 0 Configuration Choices
Table 3-43 through Table 3-49 show the configuration choices in the EMIFA/VPSS Sub-Block 0. For
instructions on how to use the different configuration choices tables for the EMIFA/VPSS Block and
Sub-Blocks, see Section 3.7.3.13.1. Note: italics in these tables indicate mandatory settings for a given
Minor Configuration option.
Before using Table 3-43 through Table 3-49 to configure the details of the EMIFA/VPSS Sub-Block 0, the
user should first select a Major Configuration Option for the EMIFA/VPSS Block (see Section 3.7.3.13.2).
After determining the Major Configuration Option (A, B, C, D, E, F, or G), the user can now use Table 3-43
through Table 3-49 to refine Sub-Block 0 pin selections:
1. Go to the table with the Major Configuration Option chosen from Table 3-42.
2. Each Major Configuration Option is further divided down into multiple Minor Configuration Options.
Select a Minor Configuration Option that best suits the application need.
3. Within the chosen Minor Configuration Option, further refine the detailed pin configurations by selecting
the settings of PINMUX0 fields CCDCSEL, HVDSEL, CWENSEL, CFLDSEL, CI10SEL, CI32SEL,
CI54SEL, and CI76SEL.
4. The PINMUX Selection Fields columns show the settings needed to program the PINMUX0 register
and PINMUX1.PCIEN field.
Table 3-43. EMIFA/VPSS Sub-Block 0 Configuration Choice A(1)
MAJOR
MINOR
PINMUX SELECTION FIELDS
RESULTING PERIPHERALS/PINS
CONFIG CONFIG
OPTION OPTION
PCIEN
AEM
AEAW
OTHERS
PCI
EMIFA
VPFE
# GPIO PINS
21 GP pins
Cfg Summary
No PCI
No EMIFA
No CCDC
0 = GP[54,
43:36]
CCDCSEL = 0
HVDSEL = 0
CWENSEL = 0
CFLDSEL = 0
CI10SEL = 0
CI32SEL = 0
CI54SEL = 0
CI76SEL = 0
0 = GP[53:52]
0 = GP[35]
A1
0
000
000
0 = GP[34]
-
-
-
0 = GP[45:44]
0 = GP[47:46]
0 = GP[49:48]
0 = GP[51:50]
A
8-to-16-bit
CCDC
0-to-12 GP
pins
Cfg Summary
No PCI
No EMIFA
1 = PCLK,
YI[7:0]
CCDCSEL = 1
-
HVDSEL = 0,1
CWENSEL = 0,1
CFLDSEL = 0,1
CI10SEL = 0,1
CI31SEL = 0,1
CI54SEL = 0,1
CI76SEL = 0,1
1 = VD, HD
1 = C_WEN
1 = C_FIELD
1 = CI[1:0]
1 = CI[3:2]
1 = CI[5:4]
1 = CI[7:6]
0 = GP[53:52]
0 = GP[35]
A2
0
000
000
0 = GP[34]
-
-
0 = GP[45:44]
0 = GP[47:46]
0 = GP[49:48]
0 = GP[51:50]
