selecting the settings of PINMUX0 fields VENCSEL, RGBSEL, CS3SEL, CS4SEL, and CS5SEL.
d. The Selection Fields columns shows the settings needed to program the PINMUX0 register.
After following the procedure in this section to determine pin functions for the EMIFA/VPSS Block, the
user should refer to Section 3.7.3.13.7, EMIFA/VPSS Block Pin-By-Pin Multiplexing Summary, for
pin-multiplexing information on a pin-by-pin basis.
3.7.3.13.2 EMIFA/VPSS Block Major Configuration Choices
Table 3-42 shows the major configuration choices in the EMIFA/VPSS Block. For instructions on how to
use the EMIFA/VPSS Block Major Configuration Choices table for the EMIFA/VPSS Block and
Sub-Blocks, see Section 3.7.3.13.1.
