TMS320C6672
Multicore Fixed and Floating-Point Digital Signal Processor
SPRS708C—February 2012
www.ti.com
Table 2-8
BAR Config / PCIe Window Sizes
32-Bit Address Translation
64-Bit Address Translation
BAR cfg
0b0000
0b0001
0b0010
0b0011
0b0100
0b0101
0b0110
0b0111
0b1000
0b1001
0b1010
0b1011
0b1100
0b1101
0b1110
0b1111
End of Table 2-8
BAR0
BAR1
32
16
16
32
16
16
32
32
64
4
BAR2
32
BAR3
32
BAR4
32
BAR5
BAR2/3
BAR4/5
PCIe MMRs
Clone of BAR4
16
32
64
32
32
64
32
32
64
16
64
64
32
64
64
32
64
64
32
64
128
256
128
256
256
64
128
128
128
256
128
128
128
4
4
256
256
512
512
1024
2048
1024
2048
2.5.2.5 I2C Boot Device Configuration
2.5.2.5.1 I2C Master Mode
In master mode, the I2C device configuration uses ten bits of device configuration instead of seven as used in other
boot modes. In this mode, the device will make the initial read of the I2C EEPROM while the PLL is in bypass mode.
The initial read will contain the desired clock multiplier, which will be set up prior to any subsequent reads.
Figure 2-7
I2C Master Mode Device Configuration Bit Fields
12
11
10
9
8
7
6
5
4
3
Reserved
Speed
Address
Reserved
Mode
Parameter Index
Table 2-9
I2C Master Mode Device Configuration Field Descriptions
Bit
12
11
Field
Description
Reserved
Speed
Reserved
I2C data rate configuration
0 = I2C data rate set to approximately 20 kHz
1 = I2C fast mode. Data rate set to approximately 400 kHz (will not exceed)
10
Address
I2C bus address configuration
0 = Boot from I2C EEPROM at I2C bus address 0x50
1 = Boot from I2C EEPROM at I2C bus address 0x51
9
8
Reserved
Mode
Reserved
I2C operation mode
0 = Master mode
1 = Passive mode (see section 2.5.2.5.2 ‘‘I2C Passive Mode’’)
7-3
Parameter Index
Identifies the index of the configuration table initially read from the I2C EEPROM
This value can range from 0 to 31.
End of Table 2-9
Copyright 2012 Texas Instruments Incorporated
Device Overview 31
