7.14 Minimum Grant Register
The minimum grant register contains the minimum grant value for the flash media controller core.
Bit
7
6
5
4
3
2
1
0
Name
Type
Default
Minimum grant
RU
0
RU
0
RU
0
RU
0
RU
0
RU
1
RU
1
RU
1
Register:
Offset:
Type:
Minimum grant
3Eh
Read/Update
07h
Default:
Table 7−9. Minimum Grant Register Description
BIT
FIELD NAME
TYPE
DESCRIPTION
7−0
MIN_GNT
RU
Minimum grant. The contents of this field may be used by host BIOS to assign a latency timer register value
to the flash media controller. The default for this register indicates that the flash media controller may need
to sustain burst transfers for nearly 64 µs and thus request a large value be programmed in bits 15−8 of
the PCI6x21/PCI6x11 latency timer and class cache line size register at offset 0Ch in the PCI configuration
space (see Section 7.6).
7.15 Maximum Latency Register
The maximum latency register contains the maximum latency value for the flash media controller core.
Bit
7
6
5
4
3
2
1
0
Name
Type
Default
Maximum latency
RU
0
RU
0
RU
0
RU
0
RU
0
RU
1
RU
0
RU
0
Register:
Offset:
Type:
Maximum latency
3Eh
Read/Update
04h
Default:
Table 7−10. Maximum Latency Register Description
BIT
FIELD NAME
TYPE
DESCRIPTION
7−0
MAX_LAT
RU
Maximum latency. The contents of this field may be used by host BIOS to assign an arbitration priority level
to the flash media controller. The default for this register indicates that the flash media controller may need
to access the PCI bus as often as every 0.25 µs; thus, an extremely high priority level is requested. The
contents of this field may also be loaded through the serial EEPROM.
