7.12 Interrupt Line Register
The interrupt line register is programmed by the system and indicates to the software which interrupt line the flash
media interface has assigned to it. The default value of this register is FFh, indicating that an interrupt line has not
yet been assigned to the function.
Bit
7
6
5
4
3
2
1
0
Name
Type
Default
Interrupt line
RW
1
RW
1
RW
1
RW
1
RW
1
RW
1
RW
1
RW
1
Register:
Offset:
Type:
Interrupt line
3Ch
Read/Write
FFh
Default:
7.13 Interrupt Pin Register
This register decodes the interrupt select inputs and returns the proper interrupt value based on Table 7−8, indicating
that the flash media interface uses an interrupt. If one of the USE_INTx terminals is asserted, the interrupt select bits
are ignored, and this register returns the interrupt value for the highest priority USE_INTx terminal that is asserted.
If bit 28, the tie-all bit (TIEALL), in the system control register (PCI offset 80h, see Section 4.29) is set to 1, then the
PCI6x21/PCI6x11 controller asserts the USE_INTA input to the flash media controller core. If bit 28 (TIEALL) in the
system control register (PCI offset 80h, see Section 4.29) is set to 0, then none of the USE_INTx inputs are asserted
and the interrupt for the flash media function is selected by the INT_SEL bits in the flash media general control register.
Bit
7
6
5
4
3
2
1
0
Name
Type
Default
Interrupt pin
R
0
R
0
R
0
R
0
R
0
R
X
R
X
R
X
Register:
Offset:
Type:
Interrupt pin
3Dh
Read-only
0Xh
Default:
Table 7−8. PCI Interrupt Pin Register
INT_SEL BITS
USE_INTA
INTPIN
00
01
10
11
0
0
0
0
1
01h (INTA)
02h (INTB)
03h (INTC)
04h (INTD)
01h (INTA)
XX
