7.5 Class Code and Revision ID Register
The class code and revision ID register categorizes the base class, subclass, and programming interface of the
function. The base class is 01h, identifying the controller as a mass storage controller. The subclass is 80h, identifying
the function as other mass storage controller, and the programming interface is 00h. Furthermore, the TI chip revision
is indicated in the least significant byte (00h). See Table 7−4 for a complete description of the register contents.
Bit
31
30
29
28
27
26
25
24
23
22
21
20
19
18
17
16
Name
Type
Default
Bit
Class code and revision ID
R
0
R
0
R
0
R
0
R
0
R
0
R
0
9
R
1
8
R
1
7
R
0
6
R
0
5
R
0
4
R
0
3
R
0
2
R
0
1
R
0
0
15
14
13
12
11
10
Name
Type
Default
Class code and revision ID
R
0
R
0
R
0
R
0
R
0
R
0
R
0
R
0
R
0
R
0
R
0
R
0
R
0
R
0
R
0
R
0
Register:
Offset:
Type:
Class code and revision ID
08h
Read-only
0180 0000h
Default:
Table 7−4. Class Code and Revision ID Register Description
BIT
FIELD NAME
BASECLASS
SUBCLASS
TYPE
DESCRIPTION
31−24
23−16
R
R
Base class. This field returns 01h when read, which classifies the function as a mass storage controller.
Subclass. This field returns 80h when read, which specifically classifies the function as other mass
storage controller.
15−8
7−0
PGMIF
R
R
Programming interface. This field returns 00h when read.
CHIPREV
Silicon revision. This field returns 00h when read, which indicates the silicon revision of the flash media
controller.
7.6 Latency Timer and Class Cache Line Size Register
The latency timer and class cache line size register is programmed by host BIOS to indicate system cache line size
and the latency timer associated with the flash media controller. See Table 7−5 for a complete description of the
register contents.
Bit
15
14
13
12
11
10
9
8
7
6
5
4
3
2
1
0
Name
Type
Default
Latency timer and class cache line size
RW
0
RW
0
RW
0
RW
0
RW
0
RW
0
RW
0
RW
0
RW
0
RW
0
RW
0
RW
0
RW
0
RW
0
RW
0
RW
0
Register:
Offset:
Type:
Latency timer and class cache line size
0Ch
Read/Write
0000h
Default:
Table 7−5. Latency Timer and Class Cache Line Size Register Description
BIT
FIELD NAME
TYPE
DESCRIPTION
15−8
LATENCY_TIMER
RW
PCI latency timer. The value in this register specifies the latency timer for the flash media controller,
in units of PCI clock cycles. When the flash media controller is a PCI bus initiator and asserts FRAME,
the latency timer begins counting from zero. If the latency timer expires before the flash media
transaction has terminated, then the flash media controller terminates the transaction when its GNT
is deasserted.
7−0
CACHELINE_SZ
RW
Cache line size. This value is used by the flash media controller during memory write and invalidate,
memory-read line, and memory-read multiple transactions.
7−5
