7.17 Power Management Capabilities Register
The power management capabilities register indicates the capabilities of the flash media controller related to PCI
power management. See Table 7−12 for a complete description of the register contents.
Bit
15
14
13
12
11
10
9
8
7
6
5
4
3
2
1
0
Name
Type
Default
Power management capabilities
RU
0
R
1
R
1
R
1
R
1
R
1
R
1
R
0
R
0
R
0
R
0
R
0
R
0
R
0
R
1
R
0
Register:
Offset:
Type:
Power management capabilities
46h
Read/Update, Read-only
7E02h
Default:
Table 7−12. Power Management Capabilities Register Description
BIT
FIELD NAME
TYPE
DESCRIPTION
15
PME_D3COLD
RU
PME support from D3
. This bit can be set to 1 or cleared to 0 via bit 4 (D3_COLD) in the general
cold
control register at offset 4Ch in the PCI configuration space (see Section 7.21). When this bit is set to
1, it indicates that the controller is capable of generating a PME wake event from D3 . This bit state
cold
implementation and may be configured by using bit 4
is dependent upon the PCI6x21/PCI6x11 V
(D3_COLD) in the general control register (see Section 7.21).
AUX
14−11
PME_SUPPORT
R
PME support. This 4-bit field indicates the power states from which the flash media interface may
assert PME. This field returns a value of 1111b by default, indicating that PME may be asserted from
the D3 , D2, D1, and D0 power states.
hot
10
9
D2_SUPPORT
D1_SUPPORT
AUX_CURRENT
R
R
R
D2 support. Bit 10 is hardwired to 1, indicating that the flash media controller supports the D2 power
state.
D1 support. Bit 9 is hardwired to 1, indicating that the flash media controller supports the D1 power
state.
8−6
Auxiliary current. This 3-bit field reports the 3.3-V auxiliary current requirements. When bit 15
AUX
(PME_D3COLD) is cleared, this field returns 000b; otherwise, it returns 001b.
000b = Self-powered
001b = 55 mA (3.3-V
AUX
maximum current required)
5
DSI
R
Device-specific initialization. This bit returns 0 when read, indicating that the flash media controller
does not require special initialization beyond the standard PCI configuration header before a generic
class driver is able to use it.
4
3
RSVD
R
R
Reserved. Bit 4 returns 0 when read.
PME_CLK
PME clock. This bit returns 0 when read, indicating that the PCI clock is not required for the flash media
controller to generate PME.
2−0
PM_VERSION
R
Power-management version. This field returns 010b when read, indicating that the flash media
controller is compatible with the registers described in the PCI Bus Power Management Interface
Specification (Revision 1.1).
