7.9 Subsystem Vendor Identification Register
The subsystem identification register, used for system and option card identification purposes, may be required for
certain operating systems. This read-only register is initialized through the EEPROM and can be written through the
subsystem access register at PCI offset 50h (see Section 7.22). All bits in this register are reset by GRST only.
Bit
15
14
13
12
11
10
9
8
7
6
5
4
3
2
1
0
Name
Type
Default
Subsystem vendor identification
RU
0
RU
0
RU
0
RU
0
RU
0
RU
0
RU
0
RU
0
RU
0
RU
0
RU
0
RU
0
RU
0
RU
0
RU
0
RU
0
Register:
Offset:
Type:
Subsystem vendor identification
2Ch
Read/Update
0000h
Default:
7.10 Subsystem Identification Register
The subsystem identification register, used for system and option card identification purposes, may be required for
certain operating systems. This read-only register is initialized through the EEPROM and can be written through the
subsystem access register at PCI offset 50h (see Section 7.22). All bits in this register are reset by GRST only.
Bit
15
14
13
12
11
10
9
8
7
6
5
4
3
2
1
0
Name
Type
Default
Subsystem identification
RU
0
RU
0
RU
0
RU
0
RU
0
RU
0
RU
0
RU
0
RU
0
RU
0
RU
0
RU
0
RU
0
RU
0
RU
0
RU
0
Register:
Offset:
Type:
Subsystem identification
2Eh
Read/Update
0000h
Default:
7.11 Capabilities Pointer Register
The power management capabilities pointer register provides a pointer into the PCI configuration header where the
power-management register block resides. Since the PCI power management registers begin at 44h, this read-only
register is hardwired to 44h.
Bit
7
6
5
4
3
2
1
0
Name
Type
Default
Capabilities pointer
R
0
R
1
R
0
R
0
R
0
R
1
R
0
R
0
Register:
Offset:
Type:
Capabilities pointer
34h
Read-only
44h
Default:
