MSP430F530x, MSP430F5310
www.ti.com
SLAS677B –SEPTEMBER 2010–REVISED MARCH 2011
Port P2, P2.0 to P2.7, Input/Output With Schmitt Trigger
Pad Logic
P2REN.x
DVSS
DVCC
0
1
1
P2DIR.x
0
1
Direction
0: Input
1: Output
From module
P2OUT.x
0
1
From module
P2.0/TA1.1
P2.1/TA1.2
P2.2/TA2CLK/SMCLK
P2.3/TA2.0
P2.4/TA2.1
P2DS.x
0: Low drive
1: High drive
P2SEL.x
P2IN.x
P2.5/TA2.2
P2.6/RTCCLK/DMAE0
P2.7/UB0STE/UCA0CLK
EN
D
To module
To module
P2IE.x
EN
Q
P2IFG.x
Set
P2SEL.x
P2IES.x
Interrupt
Edge
Select
Copyright © 2010–2011, Texas Instruments Incorporated
Submit Documentation Feedback
69
