TYPICAL LOW-LEVEL OUTPUT CURRENT
vs
LOW-LEVEL OUTPUT VOLTAGE
90
80
70
60
50
40
30
20
10
VCC = 3.0 V
TA = 25 ºC
VCC = 3.0 V
TA = 85 ºC
VCC = 1.8 V
TA = 25 ºC
VCC = 1.8 V
TA = 85 ºC
0
0
0.1
0.2
0.3
0.4
0.5
0.6
0.7
0.8
0.9
1
1.1
1.2
VOL - Low-Level Output Voltage - V
Figure 12. Ports PU.0, PU.1 Typical Low-Level Output Characteristics
TYPICAL HIGH-LEVEL OUTPUT CURRENT
vs
HIGH-LEVEL OUTPUT VOLTAGE
0
-10
-20
-30
VCC = 1.8 V
TA = 85 ºC
-40
-50
VCC = 3.0 V
-60
TA = 85 ºC
VCC = 1.8 V
-70
TA = 25 ºC
VCC = 3.0 V
TA = 25 ºC
-80
-90
0.5
1
1.5
2
2.5
3
VOH - High-Level Output Voltage - V
Figure 13. Ports PU.0, PU.1 Typical High-Level Output Characteristics
TYPICAL PU.0, PU.1 INPUT THRESHOLD
2.0
TA = 25 °C, 85 °C
1.8
VIT+, postive-going input threshold
1.6
1.4
1.2
1.0
0.8
0.6
0.4
0.2
0.0
VIT-, negative-going input threshold
1.8
2.2
2.6
3
3.4
- V
LDOO Supply Voltage, VLDOO
Figure 14. Ports PU.0, PU.1 Typical Input Threshold Characteristics
