Detection Capabilities:
–
–
Face Inclination of ±45°
Face Direction:
•
•
Up/Down: ±30°
Left/Right: ±60°
–
Supported Detection Directions:
•
•
•
•
0° Faces are Vertical
+90° Faces are Rotated Right by 90°
-90° Faces are Rotated Left by 90°
Supported Minimum Face Sizes of 20, 25, 32 or 40 Pixels
–
–
–
Supported Detection Start Positions:
•
•
X = 0 to 160
Y = 0 to 120
Supported Detection Area Sizes:
•
•
X = 160 to 320
Y = 120 to 240
Provides Size, Position, Angle, and Confidence Level for Each Face
2.8 Spinlock Module Overview
The Spinlock module provides hardware assistance for synchronizing the processes running on multiple
processors in the device:
•
•
ARM Cortex-A8 processor
Media Controller
The Spinlock module implements 128 spinlocks (or hardware semaphores) that provide an efficient way to
perform a lock operation of a device resource using a single read-access, avoiding the need for a read-
modify-write bus transfer of which the programmable cores are not capable.
