CC1110Fx / CC1111Fx
WORCTRL (0xA2) - Sleep Timer Control
Bit
7
Field Name
Reset
R/W
R0
Description
-
Not used
6:4
3
111
-
R/W
R0
Reserved. Always write 000
Not used
2
WOR_RESET
0
R0/W1
R/W
Reset timer. The timer will be reset to 4.
Sleep Timer resolution
1:0
WOR_RES[1:0]
00
Controls the resolution and maximum timeout for the Sleep Timer.
Adjusting the resolution does not affect the clock cycle counter:
Setting
Resolution (1 LSB) Bits selected from the 31-bit Sleep
Timer
00
01
10
11
1 period
15:0
25 periods
210 periods
215 periods
20:5
25:10
30:15
WORIRQ (0xA1) - Sleep Timer Interrupt Control
Bit
7:6
5
Field Name
Reset
R/W
R0
Description
00
0
R/W
R/W
Reserved. Always write 0
Event 0 interrupt mask
4
EVENT0_MASK
0
0
1
Interrupt is disabled
Interrupt is enabled
3:2
1
00
0
R0
R/W0
R/W0
Reserved
0
EVENT0_FLAG
0
Event 0 interrupt flag
0
1
No interrupt is pending
Interrupt is pending
